Specifications
The BFRL WQF-530A Pro FT-IR Spectrometer is an advanced Fourier Transform Infrared analytical instrument designed for demanding laboratory analysis, scientific research, and production quality control. Compared with the standard WQF-530A, the Pro model offers improved spectral resolution of 0.5 cm⁻¹ and a signal-to-noise ratio better than 60,000:1, according to the manufacturer's brochure.
The instrument features a DLATGS detector, a high-stability optical system, intelligent moisture protection, and integrated electronic signal processing. Its MainFTOS Suite software supports spectral acquisition, processing, analysis, and reporting. Ethernet and Wi-Fi connectivity enable instrument communication and support remote operation and maintenance workflows.
The WQF-530A Pro also supports optional advanced accessories, including ATR sampling systems, gas and liquid cells, diffuse and specular reflection accessories, and an infrared microscope.
| Specification | WQF-530A Pro |
|---|---|
| Interferometer | Cube-corner Michelson interferometer |
| Beam Splitter | Multilayer Ge-coated KBr |
| Detector | DLATGS pyroelectric detector |
| Optional Detector | MCT detector (optional) |
| IR Source | High-intensity, long-lifetime, air-cooled IR source |
| Wavenumber Range | 7800–350 cm⁻¹ |
| Resolution | 0.5 cm⁻¹ |
| Signal-to-Noise Ratio |
Better than 60,000:1
RMS value at 2100–2200 cm⁻¹, resolution 4 cm⁻¹, 1-minute data collection |
| Wavenumber Accuracy | ±0.01 cm⁻¹ |
| Scanning Speed | Microprocessor control; different scanning speeds selectable |
| Software | MainFTOS Suite software workstation, compatible with Windows operating systems |
| Compliance Software | FDA 21 CFR Part 11 compliance software (optional) |
| Interface | Ethernet and Wi-Fi wireless |
| Data Output | Standard data formats, report generation and output |
| Status Diagnosis | Power-on self-check, real-time temperature and humidity monitoring and reminders |
| Certification | CE |
| Optional Qualification | IQ/OQ/PQ |
| Environmental Conditions | Temperature: 10–30°C; humidity: less than 60% |
| Power Supply | AC 220 V ±22 V, 50 Hz ±1 Hz; AC 110 V optional |
| Dimensions & Weight | 490 × 420 × 240 mm; 23.2 kg |
| Standard Accessory | Transmission sample holder |
| Optional Accessories |
Diamond ATR accessory Gas cell Liquid cell Diffuse/specular reflection accessories Single/multiple-reflection ATR accessories IR microscope Other compatible accessories |
