Specification
Vehicular Emission Analyser OIML Class 00, Euro VI Compliant
The SGA 400 is a compact and reliable solution for petrol emission testing for Environmental Bodies & Inspection Centers globally.
Featuring a high-quality LED display, a robust aluminum casing with magnetic feet, and the AquaSense system for protection against water damage from exhaust gas, it delivers accurate results day after day.
Bluetooth and USB interfaces ensure flexible integration into modern testing environments.
For customers in colder regions such as Sweden, Norway, and Finland, our optional Arctic trolley configuration guarantees dependable operation even in extreme sub-zero conditions, making the SGA 400 a trusted choice from temperate climates to the harshest winters.
Key Features at a Glance
- AquaSense: Protects sensor system from liquid damage
- Connectivity: Supports both USB and Bluetooth
- Fast Warm-Up: Less than 10 sec for optical bench
- High Accuracy: OIML class 00 certified, suitable for Euro 6
- Software Update: Via USB for easy firmware upgrades
- Workshop-Ready: Durable, compact, and low-maintenance
Technical Specifications
| Parameter | Range | Resolution | Accuracy |
|---|---|---|---|
| CO | 0 – 10 vol.% | 0.01 | 0.02 vol.% (3%) |
| CO | 10.01 – 15 vol.% | 0.01 | 5% |
| HC | 0 – 2,000 ppm | 1 | 4 ppm (3%) |
| HC | 2,001 – 5,000 ppm | 1 | 5% |
| HC | 5,001 – 15,000 ppm | 1 | 10% |
| CO₂ | 0 – 16 vol.% | 0.01 | 0.3 vol.% (3%) |
| CO₂ | 16.01 – 20 vol.% | 0.01 | 5% |
| O₂ | 0 – 25 vol.% | 0.01 | 0.02 vol.% (1%) |
| Lambda | 0.6 – 1.7 | 0.001 | – |
| AFR | 0 – 35 | 0.01 | – |
| NOx | 0 – 5,000 ppm | 1 | – |
| RPM | 0 – 9,999 r/m | – | – |
