Specifications
The BFRL WQF-530A FT-IR Spectrometer is a high-sensitivity Fourier Transform Infrared (FT-IR) analytical instrument designed for material identification, scientific research, quality control, and routine laboratory analysis. It features a cube-corner Michelson interferometer, a high-intensity air-cooled infrared source, and a stable modular optical design for reliable performance.
The instrument supports real-time monitoring of operating conditions, Ethernet and Wi-Fi connectivity, and the MainFTOS Suite software workstation for spectral data collection, processing, analysis, and report generation. Its large sample compartment supports a range of conventional sampling accessories.
| Specification | WQF-530A |
|---|---|
| Interferometer | Cube-corner Michelson interferometer |
| Beam Splitter | Multilayer Ge-coated KBr |
| Detector | LiTaO₃ pyroelectric detector |
| Optional Detector | MCT detector (optional) |
| IR Source | High-intensity, long-lifetime, air-cooled IR source |
| Wavenumber Range | 7800–350 cm⁻¹ |
| Resolution | 0.85 cm⁻¹ |
| Signal-to-Noise Ratio |
Better than 50,000:1
RMS value at 2100–2200 cm⁻¹, resolution 4 cm⁻¹, 1-minute data collection |
| Wavenumber Accuracy | ±0.01 cm⁻¹ |
| Scanning Speed | Microprocessor control; different scanning speeds selectable |
| Software | MainFTOS Suite software workstation, compatible with Windows operating systems |
| Interface | Ethernet and Wi-Fi wireless |
| Data Output | Standard data formats, report generation and output |
| Status Diagnosis | Power-on self-check, real-time temperature and humidity monitoring and reminders |
| Certification | CE |
| Environmental Conditions | Temperature: 10–30°C; humidity: less than 60% |
| Power Supply | AC 220 V ±22 V, 50 Hz ±1 Hz |
| Dimensions & Weight | 490 × 420 × 240 mm; 23.2 kg |
| Standard Accessory | Transmission sample holder |
| Optional Accessories |
Diamond ATR accessory Gas cell Liquid cell Diffuse/specular reflection accessories Single/multiple-reflection ATR accessories IR microscope Other compatible accessories |
