testo 417 - Vane anemometer
testo 417 - Vane anemometer
Regular price
Rs.0.00 PKR
Regular price
Sale price
Rs.0.00 PKR
Unit price
/
per
Couldn't load pickup availability
Part # 0560 4172
Product Description
Volume flow is shown directly in the display. Accurate volume flow calculation thanks to easy input of duct area. In addition, it is easy to switch to the current temperature reading.
The flow direction, i.e. drawn in or blowing, is visible in the display.
Timed and multi-point mean calculation provide information on mean volume flow, flow speed and temperature readings.
The optional funnel set facilitates efficient measurements at ventilator grilles and disc outlets.
Min/max values can also be shown in the display. Current readings can be frozen in the display using the Hold function.
| Temperature - NTC | |
|---|---|
|
Measuring range |
0 to +50 °C |
|
Accuracy |
±0.5 °C |
|
Resolution |
0.1 °C |
| Velocity - Vane anemometer | |
|---|---|
|
Measuring range |
0 to +20 m/s |
|
Accuracy |
±(0.1 m/s + 1.5 % of mv) |
|
Resolution |
0.0 m/s |
|
Measuring rate |
0 to +99999 m³/h |
| Volume flow | |
|---|---|
|
Resolution |
0.1m³/h (0.0 to 99.9 m³/h) 1.0m³/h (+100.0 to 99999.0 m³/h) |
| General technical data | |
|---|---|
|
Storage temperature |
-40 to +85 °C |
|
Weight |
230 g |
|
Dimensions |
277 x 105 x 45 mm |
|
Operating temperature |
0 to +50 °C |
|
Housing |
ABS |
|
Warranty |
2 years |
|
Battery type |
9V block battery, 6F22 |
|
Battery life |
50 h |
