testo 317-1 - Back pressure indicator

testo 317-1 - Back pressure indicator

Rs.0.00 PKR
Rs.0.00 PKR
Sale Sold out

Part #  0632 3170

Product Description

Gas leaks on heating systems can quickly become a problem, because breathing in poisonous gases leads to health risks or even a risk of death. For instance, carbon monoxide harbours a particular hazard because it is colourless and odourless, but poisonous. Carbon monoxide arises when the combustion of substances containing carbon (oil, gas , solid fuels, etc.) is incomplete.

The use of professional measuring technology is recommended when there are gas leaks. The testo 317-1 back pressure indicator quickly and reliably detects escaping heating flue gases. Flue gas leaks in the area of combustion plants indicates a malfunction or blockage of the flue gas paths.

The handy instrument immediately gives an optical and acoustic alarm when gas is escaping. This means no visual contact with the measuring instrument is needed. The flexible probe even enables use in the tightest spaces or in inaccessible areas.



Delivery Scope

testo 317-1 back pressure indicator, including battery.



Ambient CO
General technical data

Weight

300 g

Reaction time

2 s

Dimensions

128 x 46 x 18 mm

Warranty

Instrument: 24 months

Measuring medium

Ambient air

Alarmsignal

audible; Optical

Battery type

3 AAA micro batteries

Length probe shaft

200 mm

Length probe shaft tip

35 mm

Diameter probe shaft tip

10 mm
