Portable Multi Spectrum BC 1054 Black Carbon Monitor by Metone

 The BC 1054 Multi Spectrum Black Carbon Monitor provides a reliable, cost effective solution for high time resolution data collected at 10 wavelengths ranging from the near-UV to near-IR

The BC 1054 Multi Spectrum Black Carbon Monitor comes standard with active flow control. Utilizing arobust design with a single mass flow controller and a single flow path, the standard configuration permits easy flow calibrations and leak tests. A high-concentration option is available and recommended for use when BC concentrations are expected to exceed 7,000 ng/m3 on a routine basis. The high concentration option extends the time between tape replacement without sacrificing sensitivity.

All BC 1054 Multi Spectrum Black Carbon Monitors are equipped with a humidity control system that may be set to maintain a constant sample temperature and thereby reduce moisture-related measurement artifacts

Applications:
•Air Quality Surveillance
•Global Warming Studies
•Particulate Emissions Studies
•Near-Roadside Monitoring
•Visibility Studies
•Climatology Studies
•Source Apportionment Determination
•Angstrom Absorption Exponent Determination

The BC 1054 offers the following advanced features:
•Active flow control at either 2 or 5 LPM.
•Compact flash storage of greater than 1-year worth of data
•Built in filter-loading correction algorithm with user selectable parameters
•Cloud service for data storage available
•Advanced diagnostics for flow, optics, and tape drive operation
•Ultra-high sensitivity with lower limits of detection less than 1 ng/m

SPECIFICATIONS:

Measurement Principle:  Filter-Based Multiple Wavelength Optical Absorption Illumination Wavelengths:  370, 430, 470, 525, 565, 590, 660, 700, 880 and 950 nm Measurement Range:  <1 ng/m3 to >100,000 ng/m3 (effective) Display Resolution  0.1 ng/m3 Limit of Detection: <8 ng/m3 with (1 minute resolution) Measurement Interval: <1 ng/m3 with (1 hour resolution)
1-minute standard (1 second optional) Flow Rate: Pump Type: 2 or 5 LPM, standard user selectable, mass flow controlled and reported under actual conditions.Internal AC vacuum pump Filter Tape:  Reinforced glass fiber Power Supply:  12 VDC Universal 100-240 VAC 50/60Hz input, 12 VDC 8.5 A output supply included Power Consumption:  50 W Operating Temperature:  0 to +40C Ambient Temperature:  -30 to +50C Ambient Humidity Range:  0 to 90% RH non-condensing Data Storage:  One USB Flash Drive Port Cloud service available, stores more than 1 year of 1-minute data Single serial output through RS-232, USB, or through Ethernet port 1,200 to 115,200 baud. Data Collection Interface:  Comet™ software and USB/Ethernet driver CD included Compatible Software: User Interface Menu-driven interface with 4x20 character backlit LCD display and dynamic keypad
