Portable Continuous Real Time E BAM Monitor by Metone

 Accuracy and precision consistent with U.S.-EPA requirements for Class III PM2.5 and PM10 measurement.

 The Met One Instruments, Inc. E-BAM is in a class of its own as a portable, real-time beta gauge, which is comparable to U.S.-EPA methods for PM2.5 and PM10 particulate measurements.

The E-BAM automates particulate measurement by continuously sampling and reporting concentration data. Data records are updated every minute. The E-BAM eliminates the involved process of filter collection and filter weighing of other more expensive, high maintenance instruments. With the adoption of beta attenuation for ambient monitoring the process has become simple, streamlined, and inexpensive

Features:
• Accuracy and precision consistent with U.S.-EPA requirements for Class III PM2.5 and PM10 measurement.
• Real-time, accurate results without correction factors, regardless of season or geographic location.
• True ambient sampling provides accurate measurement of semi-volatile nitrates and organic compounds.
• Lightweight, rugged construction is easily mounted on a tripod in minutes.
• All-weather construction allows for true ambient sampling.
• Operates on AC or DC power. Battery and Solar options available upon request.

Applications:
• Ambient Monitoring
• Dust Monitoring
• Emission Sampling
• Environmental Surveys
• Fence line Monitoring

SPECIFICATION:

Measurement Principle: Particulate Mass Concentration by Beta Attenuation Measurement Sample Time: 1 Hour W/ Selectable 1, 5, 10, 15, 30 or 60 minute averages real-time output. Flow Rate 16.7 L/min inlet flow rate; actual volumetric flow Filter Tape Continuous glass fiber filter; 30 mm x 21 m roll; > 60 days/roll Span Check Manual, 800 µg (typical, span foil included.) Beta Source 14C (carbon-14); 60 µCi ±15 µCi (2.22 MBq) Beta Detector Type Operating Photomultiplier tube with organic plastic scintillator Temperature Range Operating -30° to +50°C. Humidity Range Inlet 0 – 90% RH, noncondensing Humidity Control Actively controlled inlet heater module User Interface 4.3” graphical touch screen Ambient Sensor Model 597A combination AT, RH, and BP serial sensor AT: -50° to +70°C; RH: 0 to 98%; BP: 375 to 825 mmHg 7500 Digital Serial Interface : 2 channels, half duplex RS-485 Serial Interface 1 channel; full duplex RS-232, USB (Shared common serial output 1 channel; half duplex RS-485 Baud rates 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 Internal Data Storage External 15 Days 1-minute average, 2.6 years 60-minute average Data Storage Compatible 1 USB Flash drive device Software Air Plus 5, COMET™, HyperTerminal® Power Supply AC Version: 100 - 230 VAC; 1.4 Amp AC, 50/60 Hz; 102 W, 12 VDC @ 8.5 Amp Weight 31 lbs. (14.1 kg Dimensions (Without Tripod) Height: 18 in (46 cm) Width: 16 in (41 cm) Depth: 9 in (23 cm)
