Specifications
Handheld moisture testers that provide fast and easy results.
Measuring grain moisture straight from the field with the DICKEY-john® mini GAC™ family of handheld grain moisture analyzers. These award-winning handheld moisture testers offer the highest level of accuracy in their class, plus mini GACs are fast and easy to use.
The mini GAC™ Grain Moisture Analyzer Family Includes
- mini GAC™ – for highly accurate moisture testing.
- mini GAC™ Plus – provides test weight results, increasing the data available for producers to make the correct harvest, conditioning, and storage decisions.
Features & Benefits
- Simplifies operation with menu-driven interface.
- Eliminates pre-weighing with an internal scale.
- Avoids cumbersome screw caps that can cause grain damage and oily residue.
- Measures over 450 types of grain and products.
- Easily loads calibrations with a USB port.
- Tests hot or cold grain between 32°F and 122°F (0°C to 50°C).
- Receives accurate measurements in a variety of conditions with automatic temperature compensation.
| Specification | Details |
|---|---|
| Product | mini GAC™ / mini GAC™ Plus |
| Application | Grain Moisture Analyzer |
| Moisture Range | 5–45% (Depending on Grain Type) |
| Grain Temperature | 32–122°F (0–50°C) |
| Temperature Difference | 36°F (20°C) |
| Temperature Compensation | Automatic to Grain Sample |
| Grain Type | Whole Grain, No Sample Preparation |
| Sample Size | 1 Pint (0.47 L) |
| Display | LCD (106 × 56 Pixels) |
| Height | 11.9 in (30.2 cm) |
| Width | 4.8 in (12.2 cm) |
| Depth | 8.3 in (21.1 cm) |
| Weight | 2 lbs 7 oz (1.1 kg) |
| Measured Parameters | Moisture, Grain Temperature & Test Weight* |
| Temperature Accuracy | ±1.0°F (±0.5°C) |
| Temperature Resolution | 0.1°F (0.1°C) |
| Test Weight Repeatability | 0.5 lb/bu (0.6 kg/hl) |
| Test Weight Resolution | 0.1 lb/bu (kg/hl) |
| Operating Temperature | 40–113°F (5–45°C) |
| Humidity | 5–95% Non-condensing |
| Power Supply | 9V DC Battery |
