Handheld Particle Counter 804 by Metone

 The 804 hand held particle counter is a 4 channel portable particle counter that counts particles 0.3 microns to 10.0 microns giving you portability and reliability at the lowest price in the industry.

Key Features:
Completely Self-Contained Selectable Particle Sizes Don’t let the size fool you this unit is completely self-contained with its own internal battery and sample pump, and is programmable, allowing you to choose your particle sizes of interest from seven sizes: 0.3, 0.5, 0.7, 1.0, 2.5, 5.0 or 10.0 microns.

Fast Sampling
Unlike other counters that can take up to a minute to deliver results, the 804 incorporates user selectable sampling time up to 1 minute and displays counts in as little as 3 seconds. The unit will take single or continuous samples.

Simple Operation
Only two front-panel buttons and scroll wheel provide a user friendly, menu driven platform that provides ease in configuration.

Battery or AC Powered
The self-contained battery pack powers the unit for 30 hours of typical intermittent operation, and for up to 8 hours of continuous use. The included AC charger / adapter operates the counter, even when the battery pack is discharged, and recharges the depleted battery in 2.5 hours.

Flexible Data Interfaces / USB Communication
Stores up to 2500 records for output. USB interface provides quick data download and field firmware upgrades

Applications
• Controlled Environments
• Indoor Air Quality
• Process Control
• HVAC Applications
• Filter Testing
• Laboratory Environments
• Trace Contamination Source
• QA Programs

SPECIFICATIONS:

PERFORMANCE
Particle Size Range: Four Channels : >0.3, >0.5, >0.7, >1.0, >2.5, >5.0, and >10.0 µm (selectable)
Concentration Range: 0 – 3,000,000 particles per cubic foot (105,900 particles/L)
Accuracy: ± 10%, to calibration aerosol
Sensitivity: 0.3 µm
Flow Rate: 0.1 cfm (2.83 lpm)
Sample Time: Adjustable (3-60 seconds)
Status Indicators: Low Battery, Service

ELECTRICAL
Light Source: Laser diode, 30 mW, 780 nm
Power: 7.2V Lithium Ion self-contained battery pack—provides 30 hours of typical intermittent operation, up to 8
hours continuous use
AC Adapter/Charger: AC to DC module intelligent Lithium Ion charger, 100 – 240 VAC to 8.4 VDC @ 1500 mA typical. Charge
time 2.5 hours typical
Communications: USB
Certifications: Meets or exceeds CE, ISO, ASTM, and JIS international certifications

INTERFACE
Display: 2 line by 16-character LCD
Keyboard: 2-button membrane

PHYSICAL
Size: Height: 6.75” (17.2 cm) Width: 3.75” (9.5 cm) Thickness: 2.0” (5.1 cm)
Weight: 1.31 lb (21 oz) (0.60 kg)

ENVIRONMENTAL
Operating Temperature: 0˚ to +50˚C
Storage Temperature: -20˚ to +60˚C
