Freezer, -86 °C

Models

ULF86-60E
ULF86-590E
ULF86-410
ULF86-410P

ULF86-410E
ULF86-340
ULF86-840
ULF86-840P

ULF86-340E
ULF86-840E
ULF86-730
ULF86-730P

ULF86-190E
ULF86-730E
ULF86-590
ULF86-590P

Reliability
Positive filed proven reliability record.
Specialized control system design for a well-balanced operation of
cascade(dual) refrigeration system.

Key Features

Microprocessor-controlled system designed with 1°C increment.
Settable high temperature and low temperature alarms.
Automatic clean-filter alarm and sensor error alert.
Adjustable storage shelf height.
Double security with two independent cooling system, when one system
breakdown, the other system could maintain the inner temperature at
-70°C. (Only for P series)

Multifunctional alarms including high and low temperature, power
failure, sensor error, clean-filter, and extremely high ambient, abnormal
voltage, thermostat failure, low battery, condenser clean, door ajar.
Capable of producing two types of alarm outputs, audible
buzzer and visible flashing light.

Door open feature standard and USB port for temperature
date downloading standard on upright models.

Remote alarm contacts.

Energy Conservation

High performance V.I.P(Vacuum Insulation
Panel) insulation panels to minimize
cabinet heat gain and to improve
temperature stability.

Unique insulated inner door design for four
separate storage compartments to
minimize frost buildup inside the chamber.
Unique door seal design for the minimum
loss of cold temperature during a door
opening.

HC Refrigerant with better efficiency & less
energy cost, good for environment.
(Except for the E series)

Optional

Temperature recorder,frozen racks and frozen boxes ,back up system (CO2 / LN2).

Application

It is suitable for low temperature test of special materials and preservation of plasma, biological
materials, vaccines, reagents, biological products, chemical reagents, strains, biological
samples, etc.
