Extech EN300 5-in-1 Environmental Meter

Measures Humidity, Temperature, Air Velocity, Light and Sound

The EN300 Measures Humidity, Temperature, Air Velocity, Light and Sound. Rugged 5-in-1 environmental meter with tripod mount and RS-232 PC interface. Large dual LCD simultaneous display of Temperature and Air Velocity or Relative Humidity. Characters on display reverse direction depending on Hygro-Thermo-Anemometer or Light-Sound Mode. Data Hold, Min/Max, Auto power off, Low Battery/Overrange indication. Built-in low friction vane wheel improves accuracy of air velocity in ft/min, MPH, m/s, km/h, and Knots. Built-in precision thin-film capacitance humidity sensor for fast response. Built in thermistor for ambient temperature measurements. Type K input measures temperature to 2372° (1300°C). Utilizes precision photo diode and correction filter for Cosine and color corrected light measurements. Sound Level measurement meets IEC 61672 class 2 using A frequency weighting and fast response time. Complete with Type K thermocouple probe, pouch case, and six 1.5V AAA batteries.

5-in-1 Environmental Meter Features:

• Rugged environmental meter with tripod mount and RS-232 PC interface
• Large dual LCD simultaneous display of Temperature and Air Velocity or Relative Humidity
• Characters on display reverse direction depending on Hygro-Thermo-Anemometer or Light-Sound Mode
• Data Hold, Min/Max, Auto power off, Low Battery/Overrange indication
• Built-in low friction vane wheel improves accuracy of air velocity in ft/min, MPH, m/s, km/h, and Knots
• Built-in precision thin-film capacitance humidity sensor for fast response
• Built in thermistor for ambient temperature measurements
• Type K input measures temperature to 2372°F (1300°C)
• Utilizes precision photo diode and correction filter for Cosine and color corrected light measurements
• Sound Level measurement meets IEC 61672 class 2 using A frequency weighting and fast response time
• Complete with Type K thermocouple probe, pouch case, and six 1.5V AAA batteries

Measurements                             Range
Air Velocity
ft/min                                       80 to 5910 ft/min
m/s                                          0.4 to 30m/s
km/h                                        1.4 to 108km/h
MPH                                        0.9 to 67MPH
knots                                       0.8 to 58.3 knots
Light
Foot Candles                         0 to 1860Fc
Lux                                           0 to 20,000Lux
Relative Humidity                 10 to 95%RH
Temperature
Thermistor                             32 to 122°F (0 to 50°C)
Type K                                    -148 to 2372°F (-100 to 1300°C)
Sound
dB                                             35 to 130dB
Frequency                               31.5 to 8,000Hz
Weighting/Response            A weighting/fast response
Power                                      6 x AAA batteries
Dimensions Meter:               9.8 x 2.8 x 1.3" (248 x 70 x  34mm); Vane: 1.2" (31mm)
Weight                                     11.8oz (335g)
