Specifications
The Skyray EDX 3200S Plus is an Energy Dispersive X-Ray Fluorescence (EDXRF) spectrometer specifically developed for sulfur analysis in petroleum. It uses a sealed helium sample chamber and an X-ray detector to analyze up to 24 elements simultaneously, covering Sulfur (S) through Uranium (U).
The instrument is designed for on-site or laboratory use and supports analysis of both solid and liquid samples without sample preparation. Its one-key operation, heavy X-ray shielding, and portable design make it suitable for routine elemental analysis in petroleum and petrochemical applications.
Key Features
- Specifically developed for sulfur in petroleum analysis
- EDXRF analytical technology
- W-target X-ray tube
- Electro-cooled Si-Pin semiconductor detector
- Sealed helium-charged sample chamber
- No sample preparation required
- Analysis of solids and liquids
- Up to 24 elements simultaneously
- Heavy X-ray shielding
- One-key operation
- Portable design for on-site or laboratory use
- Analysis range from 3 ppm to 99.999%
- Sulfur detection limit of 10 ppm, or 3 ppm with helium gas
| Specification | EDX 3200S Plus |
|---|---|
| Product Type | X-Ray Fluorescence Spectrometer |
| Application | Sulfur in Petroleum Analysis |
| Measurable Elements | Sulfur (S) – Uranium (U) |
| Limit of Detection | 10 ppm (3 ppm with Helium gas) |
| Analysis Range | 3 ppm – 99.999% |
| Test Time | 50–100 seconds |
| Detector | Electro-cooled Si-Pin Semiconductor Detector |
| X-Ray Tube | W-Target X-Ray Tube |
| Simultaneous Analysis | Maximum 24 elements |
| Sample Chamber | Sealed Helium-Charged Chamber |
| Sample Type | Solids and Liquids |
| Working Temperature | 10–35 °C |
| Instrument Size | 37 × 36 × 42 cm |
| Weight | 30 kg |
| Power Supply | AC 220 V ± 5 V / AC 110 V ± 5 V |
| Operation | One-key operation |
