Application

This product is suitable for seed germination, seedling cultivation, and microbial culture, as well as the rearing of insects and small animals. It is also designed for BOD determination in water quality monitoring, and aging and lifespan testing of medicinal materials, wood, and building materials, as well as other dedicated testing applications requiring controlled light, constant temperature, and constant humidity.

Features

  • Outer casing material: Cold-rolled steel plate with powder coating; Inner chamber material: SUS304 stainless steel plate.
  • Microcomputer intelligent PID temperature controllerfor precise temperature control; Equipped with parameter memory function, automatically resuming operation after power restoration.
  • Uses SECOP refrigeration compressor, high efficiency and low consumption; uses environmentally friendly refrigerant.
  • The inner chamber is equipped with a fan to create micro-airflow circulation, improving the temperature uniformity inside the chamber.
  • Equipped with a built-in water tank and automatic water replenishment interface.
  • Automatically disconnects the power supply to the humidification heater when there is no water detected.
  • The inner chamber adopts an arc structure design for easy cleaning.
  • Pull-out removable shelves with adjustable spacing.
  • Equipped with casters for easy movement.
  • Standard φ35mm test hole.
  • Standard USB data storage.
  • (Optional) Independent external temperature protection device.
  • (Optional) Microthermal printer or dot matrix printer.
Specification ICB-CC180Y ICB-CC290Y ICB-CC400Y ICB-CC520Y
Capacity (L) 173 288 400 516
Circulation Mode Forced Convection
Internal Dimensions (W × D × H) mm 550 × 450 × 700 600 × 600 × 800 800 × 550 × 910 800 × 710 × 910
External Dimensions (W × D × H) mm 700 × 840 × 1590 800 × 990 × 1690 1000 × 910 × 1800 1000 × 1070 × 1800
Temperature Range (°C) With Lighting: 10–65°C
Without Lighting: 0–65°C
Temperature Uniformity ±1°C
Temperature Fluctuation ±0.5°C
Temperature Display Accuracy 0.1°C
Temperature Control Accuracy ±0.1°C
Humidity Range 40% RH – 95% RH (Chamber Temperature >10°C)
Humidity Fluctuation ±3% RH
Humidity Display Accuracy 1% RH
Humidity Control Accuracy ±1% RH
Humidification Method Built-in Electric Heating Humidification Water Tank
Illumination 6000 LX Single-sided LED Light Source
Illumination Control 5-Level Adjustable
Controller PID Temperature Controller, 24-Segment Program
Display LCD
Shelves 3 3 3 3
Alarm Types Over-temperature Alarm, Under-temperature Alarm, Temperature Probe Failure Alarm, Humidity Probe Failure Alarm
Voltage / Frequency 1Ø, 220V / 50Hz
Power Consumption (W) 2000 2000 3000 3000
Net / Gross Weight (kg) 165 / 209 203 / 256 218 / 278 237 / 297
