 Constant 150 test / hour with double reagent
 80 reagent positions
 Automatic liquid level sensing, anti-collision
protection.
 Integrated full closed optical system, multi
wavelength simultaneous detection.
 New amorphous optical plastics reaction cups,
perfect transmittance.
 Maintenance free semiconductor solid state
refrigeration
 Friendly surface and easy to operation
 Multifunctional precision sampling probe
 ◆
 ◆
 Model
 ◆
 External & internal mirror polish, external & internal probe washing
 Dedicated sampling probe equipped with sensitive liquid sensor,
timely feedback of reagent & sample residuals
 Collision protection, automatic probe depth adjusting
 Excellent mixer design
 ◆   Teflon coating mixer. No water dropping (reducing carry-over)
 ◆   Excellent mixing effect with standard mixing procedure
 Model
 High precision ceramic syringe
 ◆   Permanent ceramic piston
 Model
 ◆   Accurate dispensing as low as 0.1 µl
 Reagent & sample tray
 ◆   80 reagent positions (40 for Rl, 40 for R2)
 ◆   40 sample positions, micro cup & test tube can be used
 ◆   Non-stop cooling system with peltier pad inside, 24 hours 2°C-14°C
 ◆   Bar code reader(optional)
 Reaction tray
 ◆  44 cuvettes
 ◆  Reaction volume as low as 150 µl
 ◆  Stable & accurate temperature(37±0.1 °C) for reaction
 Advanced operating system
 User friendly software interface simple, easy-to-operation
 Sample automatic dilution(decrease, increase, normal)
 Reaction result automatic checking and warning, calibration result
automatic checking, warning alarm log
 Linear & nonlinear call bration,Multi-points calibration up to 8 points
 Quality control apply to westgard, L-T plot, cumulative
