Specifications
Applications
The product is applicable to scientific research institutes, colleges and production departments engaged in environmental protection, epidemic prevention, drug test, livestock and aquatic products. It’s a dedicated thermostatic equipment for water analysis and measure, culture and conservation of bacteria, mucedine and microorganism, plant cultivation and breeding experiment.
Specifications
| Specification | ICB-B70E / ICB-B70 | ICB-B150E / ICB-B150 | ICB-B250E / ICB-B250 |
|---|---|---|---|
| Cycle Mode | Forced convection | ||
| Temperature Range | 0～65℃ | ||
| Temperature Resolution Ratio | 0.1℃ | ||
| Temperature Motion | High Temp.: ±0.5℃ Low Temp.: ±1℃ | ||
| Temperature Uniformity | ±1.5℃ | ||
| Inner Chamber | Mirror Stainless Steel | ||
| Outside Material | Cold rolling steel electrostatic spraying exterior | ||
| Insulation Layer | Polyurethane | ||
| Heater | Stainless steel heater | ||
| Power Rating | 0.8 kW | 1.0 kW | 1.2 kW |
| Compressor | Air-cooled hermetic compressor | ||
| Cryogen | R134a | ||
| Defrost Structure | Automatic control intelligent defrosting | ||
| Test Hole | Inner diameter 43 mm (one) | ||
| Controlled External Power Supply | Outer universal socket (one), inner waterproof socket (one) | ||
| Temperature Setting Mode | Touch button setting | ||
| Temperature Display Mode | Measuring temperature: LCD upper screen; setting temperature: lower row | ||
| Timer | E model: 0～99.9 h; Without E model: 0～99.9 h × 10 segment (with timing wait function) | ||
| Operation Function |
E model: Fixed value operation, timing function, auto stop. Without E model: Program operation |
||
| Sensor | PT100 | ||
| Additional Function |
E model: LED light, deviation correction, menu key lock, power failure parameter memory. Without E model: Loop self diagnosis, sensor fault alarm |
||
| Safety Device | Over temperature alarm | ||
| Inner Chamber Size (W × L × H) | 415 × 350 × 500 mm | 490 × 400 × 750 mm | 500 × 500 × 950 mm |
| Exterior Size (W × L × H) | 571 × 591 × 1051 mm | 646 × 641 × 1301 mm | 656 × 741 × 1501 mm |
| Packing Size (W × L × H) | 676 × 680 × 1235 mm | 751 × 730 × 1490 mm | 761 × 830 × 1690 mm |
| Volume | 70 L | 150 L | 250 L |
| Load per Rack | 15 kg | ||
| Shelf Number | 5 | 9 | 12 |
| Shelf Space | 60 mm | ||
| Power Supply / Current Rating | AC 220 V / 2.3 A | AC 220 V / 3.6 A | AC 220 V / 5.5 A |
| NW / GW | 69 / 92 kg | 86 / 114 kg | 100 / 139 kg |
| Accessory – Shelf | 2 | 2 | 2 |
| Accessory – Shelf Frame | 4 | 4 | 4 |
| Optional Accessories | Shelf, touch screen controller, RS485 interface, printer, remote control, USB data storage | ||
