Measures Acceleration, Velocity and Displacement plus RPM and Linear Surface Speed
This Combination Vibration Meter and Laser Tachometer measures Acceleration, Velocity, Displacement plus Contact/Non-Contact RPM and Linear Surface Speed. Vibration Meter features remote sensor with magnetic adapter on 39-Inch cable, 10Hz to 1kHz frequency range, RMS or Peak value modes, and manual/auto store of up to 1000 readings. Tachometer features a laser for non-contact measurements of up to 4.9-feet, plus store/recall of last/min/max readings. Characters on the display reverse direction depending on contact, photo, or vibration mode. Meter comes complete with remote vibration sensor, magnetic mount, wheels for linear surface speed, reflective tape, 4 AA batteries, software with cable, and hard carrying case.

Vibration Meter + Laser/Contact Tachometer Features:
Remote vibration sensor with magnetic adapter on 39"(1m) cable
Wide frequency range of 10Hz to 1kHz
RMS or Peak Value measurement modes
Manual/Auto store/recall up to 1000 readings
Data Hold and Auto shut-off
Contact and Non-Contact (Laser) tachometer functions
Uses a laser for greater distance non-contact measurements up to 4.9ft (1.5m)
Large LCD with characters on display reverse direction depending on contact, photo, or vibration mode
Windows® 95/98/NT/2000/XP compatible software (included) allows captured readings to be downloaded to your PC for further analysis

Specifications                  Range
Vibration Meter
Acceleration                656ft/s2, 200m/s2, 20.39g (peak)
Velocity                         7.87in/s, 200mm/s, 19.99cm/s (peak)
Displacement                0.078in, 2mm (peak-to-peak)
Resolution                    1ft/s2, 0.1m/s2, 0.01g; 0.01in/s, 0.1mm/s, 0.01cm/s;
                                       0.001in, 0.001mm
Basic accuracy             ±(5%+2 digits)
Tachometer
Photo                           10 to 99,999rpm
Contact                       0.5 to 19,999rpmΩ
Surface Speed            0.2 to 6,560ft/min (0.05 to 1,999.9m/min)
Basic accuracy           ±(0.05%+1 digit)
Dimensions               7.4 x 3 x 1.8" (188 x 75.5 x 46.8mm)
Weight                      1.12lbs (507g)
