testo 317-2 Methane Gas leak detector

Part # 0632 3172

Product Description

Leaky gas pipes not only lead to higher gas consumption, but can also trigger explosions and fires in the worst case scenario. Because leaks are often difficult to detect with the naked eye (for example with smallest hairline cracks), gas measuring technology is useful when it comes to testing gas pipes.

Gas pipe connections can be safely and efficiently tested with the testo 317-2 gas leak detector. The handy gas detector for new users detects two types of gas: methane and propane. The gas concentration is shown via a bar display. In addition, the gas leak detector indicates increasing gas concentrations via an acoustic alarm. The measuring instrument also confirms acoustically that it is ready for measuring.

Delivery Scope

testo 317-2 gas leak detector, including carrying bag with belt clip, wrist strap and battery.

Methane (CH₄)
Measuring range	0 to 20000 ppm
Lower response threshold	100 ppm
1st alarm limit	10000 ppm (20% LEL)

Propane (C₃H₈)
Measuring range	0 to 10000 ppm
Lower response threshold	50 ppm
1st alarm limit	5000 ppm (20% LEL)

General technical data
Storage temperature	-20 to +50 °C
Weight	< 300 g
Reaction time	t90 < 5 s
Operating temperature	-5 to +45 °C
Warranty	2 years
Heat up time	60 s
Battery type	2 batteries type micro AAA 1.5 V (LR03)
Battery life	4 h (LR03)
Display type	8 segment trend display
