Specification
MultiMeter/1000V Insulation Tester with Wireless PC interface (915MHz):
The MG300 is a True RMS multimeter with built-in insulation resistance tester with the added safety of wireless data streaming for remote monitoring and data logging. By adding insulation testing capabilities to the ubiquitous digital multimeter, electricians are always equipped for insulation testing, helping make it a more routine part of predictive maintenance with faster troubleshooting and repairs without additional tools. The rugged and waterproof (IP67-rated) combination meter includes a digital insulation resistance tester (or megohmmeter) with 4 different test voltages for measuring resistance up to 4GΩ with 0.001MΩ resolution. Complete with remote receiver with USB cable, windows compatible software, heavy duty test leads, alligator clip test lead, type K bead wire temperature probe with adapter, carrying case, and 6 x AA batteries.
- Wireless USB interface transmits measurement data to a PC
- Backlit super large triple display
- 125V, 250V, 500V, and 1000V test voltages
- Insulation Resistance from 0.001MOhm to 4000MOhm
- Auto discharge of capacitive voltage
- Lock Power On Function for hands-free operation
- Data Hold, Min/Max, Relative mode, Auto power off
- Complete with USB receiver, Windows® software, test leads & alligator clips, bead wire temperature probe, carrying case and batteries
Specifications Range
Insulation Tester Insulation Resistance 4MΩ, 40MΩ, 400MΩ, 4000MΩ
Insulation Test Voltages 125V, 250V, 500V, 1000V
Multimeter
AC Voltage 1000V
DC Voltage 1000V
AC Current 10A
DC Current 10A
Resistance 40MΩ
Capacitance 40mF
Frequency 100MHZ
Duty Cycle 0.1 to 99.9%
Temperature -58 to 1832°F
-50 to 1000°C
4-20mA% -25 to 125%
Continuity/Diode Yes
Power source 6 x AA batteries
Dimensions 7.8 x 3.6 x 1.9” (200 x 92 x 50m
Weight 20.5oz (582g)
