Specification
(Analyzer Only. Sensors, Probe & accessories are sold separately)
Download Brochure
Download Instruction Manual
Download Testo Easy Emission Software Instruction Manual
Part # 0632 3340
TUV Approved
According to EN 50379
Professional Gas Analyzer
Compact, Portable Gas Analyzer
Ideal for O2 , CO , CO2 , NO , NO2 , NOx , SO2 , H2 gases ( Selectable)
Rugged, compact handheld design.
Multi-sensor capability equipped to handle extreme concentrations and automatic sensor protections
CO Range Extension Possible upto 5%
Blue tooth optional
Probes
Flue Gas temperature 500 °C , 1200 °C , 1800 °C ( Selectable ).
Probe Length 335 mm , 700 mm , 1000 mm , 2000 mm , ( Selectable )
Flue Gas Analyzer for Semi Continuous measurements, LCD display, suitable for O2, CO (H2), CO low, NO, NO Low, NO2, SO2, & CO2 & NOx & H2 gases as calculated, Diagnosis Function Key for error reports issues, Simple function keys to navigate throughout the menu information button to display functions, sensor diagnostics, Rubberized shock-resistant housing Integrated magnets for hands-free operation, Automatic 2x and or 5x dilution system as optional, Automatic flow controlled sampling pump, Calibration records with sensor output/life graph, Integrated pressure sensor, Measure draft or differential pressure, Simultaneously measure exhaust gas and flow velocity, Efficiency Net, Efficiency Gross, Flue gas loss, Flue gas dewpoint, differential temperature, Differential pressure, 18 fuels to choose from plus 10 user defined fuels (input from easy Emissions), Internal data logging, Up to 100 folders (custom/systems) can be saved, Up to 10 sites can be saved in every folder, USB Interface, Transmit data via Bluetooth/Infrared, easy Emissions A powerful and efficient software tool, Custom report generation, Onboard diagnostics, Multi-sensor flexibility. Laptop with Licensed Operating system & easy Emission Software for Real Time Analyzer Control, showing tabular, graphical and picture box results, Instructional manual CD, easy Emission Software CD, Standard Probe lengths are from 12 inches to 28 inches with temperatures from 500C to 1800 ºC and hoses pipe can extend from 2.2 meter to 8 meter for extreme tuning flexibility, Durable Hard transport carrying case. Optional Infrared printer, Carrying Case, Filters etc
Sensors Specifications:
|
|
Gases |
Normal Range |
High Range |
Very High Range |
Display |
|
1 |
O2 |
0 ~ 25% |
25% |
25% |
0.01% |
|
2 |
CO (H2) |
0~10,000 ppm |
20,000 ppm |
50,000 ppm |
1 ppm |
|
3 |
CO (H2) (Low) |
0 ~ 500 ppm |
1,000 ppm |
25,00 ppm |
0.1ppm |
|
4 |
NO |
4,000ppm |
8,000 ppm |
20,000 ppm |
1ppm |
|
5 |
NO (Low) |
300ppm |
600 ppm |
1,500 ppm |
0.1ppm |
|
6 |
NO2 |
500ppm |
1,000 ppm |
1,000ppm |
0.1ppm |
|
7 |
SO2 |
5,000ppm |
10,000 ppm |
25,000 ppm |
1ppm |
|
8 |
NOx |
Calculated |
- |
- |
- |
|
9 |
CO2 |
Calculated |
- |
- |
- |
* Always Specify System Required as Normal, High or Very High at the time of ordering
