testo 330-1 LL - Flue gas analysis set with Bluetooth

testo 330-1 LL - Flue gas analysis set with Bluetooth

Regular price Rs.0.00 PKR
Regular price Sale price Rs.0.00 PKR
Sale Sold out

Description

The testo 330-1 LL flue gas analyzer makes customer service and maintenance pleasingly uncomplicated and so also more efficient. The high-quality instrument impresses with the successful combination of outstanding sensor technology, longevity and reliability.

testo 330-1 LL flue gas analysis set with Bluetooth in detail

testo 330-1 LL flue gas analyzer, TÜV-tested according to 1st German Federal Immission Control Ordinance (BImSchV) and EN 50379, Parts 1 to 3:
  • High-quality long-life measuring cells: sensors for O2 and CO are included in the scope of delivery – the CO cell is H2-compensated
  • Free flue gas App for iOS and Android devices (available as a download)
  • The sensors have a service life of up to 6 years. This means at least one sensor replacement is saved in the course of a normal operating life
  • 4-year warranty without maintenance contract on the instrument and O2 and CO sensor
  •  Logger function for easy long-term recording of the measurement profile, large memory for up to 500,000 readings
  • Pressure measurement up to 300 mbar
  • Integrated magnets for easy fixing during the measuring process
  • Condensate trap: easy-to-empty collection vessel in the instrument
  • User-defined fuels
  • IrDa/Bluetooth interface for data transfer to pocket PC/laptop/printer
  • ZIV driver for standard industry software
  • Integrated customer data memory

Modular flue gas probe, TÜV-tested:
  • On the TÜV-tested modular flue gas probe with 180 mm long probe shaft, the flue gas path and temperature channel can easily be connected to the measuring instrument via a practical bayonet lock
  • The probe shaft is really easy to replace, thanks to the quick-change click system on the handle
  • The thermocouple NiCr-Ni, which is integrated in the probe shaft, enables temperature measurement up to 500°C
Combustion air temperature probe:
  • The combustion air temperature probe can be positioned flexibly, as it has a probe shaft length of 190 mm and a cable length of 2.2 m
  • Pressure connection set: The pressure connection set enables the measuring instrument to be used to measure gas or air pressure. To do this, the hoses are attached to the test nipple of the measuring point and connected to the flue gas analyzer via the measuring instrument adapter
testo BLUETOOTH® printer:
  • The testo BLUETOOTH® printer preserves your readings in black and white. It enables immediate printout of readings, including date and time

Delivery Scope

  • testo 330-1 LL flue gas analyzer with O2 and CO H2-compensated sensors, Bluetooth interface, rechargeable battery and calibration protocol (0632 3306 70)
  •  Mains unit for connection to the testo 330-1 LL flue gas analyzer (0554 1096) Modular flue gas probe 180 mm; Ø 8 mm; Tmax 500°C; TÜV-tested; hose 2.2 m (0600 9760)
  • Pressure connection set with 2 silicone hoses (Ø 6 mm and Ø 4 mm, each 1 m long) and measuring instrument adapter (0554 1203)
  • Combustion air temperature probe, length 190 mm, including cone for attachment (0600 9787)
  • esto BLUETOOTH® printer with wireless Bluetooth interface, 1 roll of thermal paper and 4 mignon batteries (0554 0620)
  • Professional instrument case for instrument, probes and accessories; height 130 mm (0516 3300)
